Armoured patch cord Home / Fiber Optic Patch Cord / Armoured patch cord Fiber Optic Patch Cord And Pigtail Armoured patch cord Armoured patch cord is part of OTSCABLE's current fiber optic patch cord and pigtail range for distributors, installers and project buyers. Review the published product information below, then confirm the required configuration, quantity, packaging and destination before quotation. Steel tape armoured inside outer jacket Resist damage by improper twist Resistance of pressure and rodent bite Different fiber optic connector types optional Low insertion loss Request a Quote → Specifications Armoured patch cord Specifications Review the specification sections and product information currently published for this product. Technical Parameters Details Features Application Parameter Unit FC, SC, LC/ Armoured fiber patch cord ST, MU MT-RJ, MPO E2000 SM MM SM MM SM MM SM PC UPC APC PC PC UPC PC PC UPC PC PC APC Insertion loss(typical) dB ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.3 ≤0.3 Return loss dB ≥45 ≥50 ≥60 ≥30 ≥45 ≥50 ≥30 ≥45 ≥50 ≥35 ≥55 ≥75 Operating wavelength nm 1310, 1510 1310, 1510 1310, 1510 1310, 1510 Exchangeability dB ≤0.2 ≤0.2 ≤0.2 ≤0.2 Vibration dB ≤0.2 ≤0.2 ≤0.2 ≤0.2 Operating temperature ℃ -40~75 -40~75 -40~75 -40~75 Storage temperature ℃ -45~85 -45~85 -45~85 -45~85 Cable diameter mm φ3.0, φ2.0, φ0.9 φ3.0, φ2.0, φ0.9 φ3.0, φ2.0, φ0.9 φ3.0, φ2.0, φ0.9 A patch cord is a fiber optic cable used to attach one device to another for signal routing.Armoured fiber optic patch cords are with stainless steel tube inside the outer jacket to protect the central unit of the cable. They are strong and flexible, can be bend randomly without being broken. Steel tape armoured inside outer jacket Resist damage by improper twist Resistance of pressure and rodent bite Different fiber optic connector types optional Low insertion loss Custom cable lengths optional Testing equipment FTTX+LAN Optical fiber CATV Optical communication system Telecommunication Applications Where Armoured patch cord Fits Match connector type, fiber mode and cable construction to the equipment and distribution interface. Final configuration should follow the project specification. Application 01 Data Center Interconnects Connect optical equipment and distribution panels within organized rack environments. Data CenterInterconnect Application 02 Telecom Equipment Coordinate connector interfaces and cable length across optical communication equipment. TelecomEquipment Application 03 ODF & Patch Panels Use pre-terminated assemblies between distribution hardware and active devices. ODFPatch Panel Application 04 Testing & Maintenance Confirm connector, mode, length and protection for test and replacement requirements. TestingMaintenance Related Products Compare Related Fiber Optic Patch Cord And Pigtail Options Bundle multi fiber pigtail D4-D4 patch cord FC-FC patch cord LC-LC patch cord Request A Quote Write to Us Share cable type, category, shielding, length, quantity, packaging and destination details. OTSCABLE can review your project and recommend suitable product options. Email[email protected] Phone+86 (0) 755-23769401 Office Address708 Fuben Building, Guanlan Avenue, Longhua New District, Shenzhen, Guangdong, China Request a Product Quote Tell us what you need. Fields marked * are required. Name * Email * Phone Company Message * Δ
Application 01 Data Center Interconnects Connect optical equipment and distribution panels within organized rack environments. Data CenterInterconnect
Application 02 Telecom Equipment Coordinate connector interfaces and cable length across optical communication equipment. TelecomEquipment
Application 03 ODF & Patch Panels Use pre-terminated assemblies between distribution hardware and active devices. ODFPatch Panel
Application 04 Testing & Maintenance Confirm connector, mode, length and protection for test and replacement requirements. TestingMaintenance
